F117
(coming in 2010)
For
12 to 16 kg (26~36 lbs.) thrust engine
Designed by Eric Rantet
F117 1/8 scale
Span: 1.55m - 61’’
Length: 2.41m - 95’’
Weight with turbin:e 12 ~ 14 kg 26 ~ 30lbs
Turbine:
1 single turbine, 12 kg ( 26 lbs ) to 16 kg ( 37 lbs ) thrust
The
F-117 is one of the most impressive planse of the 80’s.
It has been the Star of ‘’Desert Storm’’
and Gulf War. It was the first stealth jet and its design
was very unique.
For
the first time in the jet model world, Aviation Design now
produces this incredible fighter in ARF.
The stealth fuselage with special shape is exactly reproduced
with facets and all panel lines and stealth hatches are
engraved or in relief. Redesigned from our original small
ducted fan kit, the model was improved a lot with more details,
bigger size and designed for single turbine use.
The
F117 is surprisingly very easy to fly. It is also very stable
without gyro and has gentle stall characteristics
The
F117 comes to you finished, fully molded in composite material
and painted in black with panel lines engraved. All bulkeads
are glued. This model has plug in wings and rudders for
easy assembly and transport. All necessary hardware are
included in the kit with aluminium control horns, stab mountings,
hatch latches, screws etc.
The
big fuselage hatch gives a good access to the radio, batteries,
engine equipment, fuel tank, pump and to the bifurcated
tailpipe especially designed for this model.
F-117 ARF model includes:
-
Cockpit
detail kit incl. 1/8 jet pilot, 1/8 ejector seat &
instrument panel
-
Retractable
landing gear incl. 2 main retracts + 1 front retract +
air control system + 3 oleo legs
-
Retractable
landing gear + electrovalve
-
Wheels
set + brakes incl 2 main wheels + front wheel, aluminium
hub + bearings + brakes + air control system
-
Wheels
set + brakes + electrovalve
-
Gear
doors set incl. air cylinders, air control system, gear
door sequencer and door hinges
-
Gear
doors set + electrovalve
-
2x2.2
liters kevlar fuel cells incl. tubing, nipples and clunks
-
2x2.2
Kevlar fuel tanks + Air Trap
-
Special
SCALE double wall stainless steel tail pipe
-
Super
scale water decals : USAF 512 TSF
